F-series

Pull-up speed of 0.1mm/sec type

Model	F225	F400	F525	F675
Material of Main body	Aluminium（A505)、SUS stainless steel（SUS304)
External Dimensions of Main body	width 400mm depth 350mm height 724.5mm	width 500mm depth 400mm height 1110.5mm	width 600mm depth 400mm height 1357mm	width 750mm depth 650mm height 1645mm
External Dimensions of Control box	width 250mm　depth 285mm　height 167mm
Weight of Main body	15kg	20kg	25kg	45kg
Weight of Control box	5kg
Processing speed	0.1mm/sec～30mm/sec（Variable in 0.1mm/sec increments）
Processing stroke	225mm	400ｍｍ	525ｍｍ	675mm
Max. workpiece weight	1kg
Machine cover	Option
Number of set points	10 points
Number of Programs	8 programs
Operation Monitor	Current Speed、Current Position、Remain Time
Other Functions	Emergency Stop、Partitive / Overall Repeat、Manual mode
Power supply used	1φAC100V
Amount of electricity consumed	250VA
Input interfaces	Touch Panel

【Field of use】 ※Fields in bold type are those in which the product is used.

Optical Function	Electronic Function	New Materials	Medical
Particle Array（Opal Membrane・Photonic Crystal）	Ferroelectric film	Foamed metal/ Porous metal	Catheters
Solar Cell	Insulator layer	Organic / Inorganic Hybrid Materials（Alternating Layering・Alternate Adsorption・Nanosheets）	Pharmaceutical R&D
Dye-sensitized solar cell、DSC	Alignment Film	Surface Hardener Coating	DNA chip （Cell culture sheet）
LED	Photoresist Materials	CNT	Microfluidic channels
Photocatalysts	LCD	Functional Ceramic Materials	Biodevice Reactor
Optical Lens	OLED	Non-woven fabrics	etc.
Optical Storage Device （CD / HDD）	Transparent Conductive Film	Prepreg
Anti-Reflection Coating	Fuel Cells	Specialty Films
etc.	Hydrogen Separation Membrane	Heat Transfer Materials / Heat dissipating materials
	Nanoimprint Lithography、NIL	Filter Material
	etc.	Beverage Container （PET bottle・Glass bottle）
		Cutting Material
		etc.
